Product Characteristic:
1. Adapt to cylindrical and barrel shape springs.
2. The heat-treatment device can adapt to different spring height, easy for adjustment.
3. The non-woven feeder system, save material and labor.
4. Multiple fault detecting device, effectively reduced the wastage.
5. Use full-automatic coiling head, can make high compression springs and zone mattress, all parameters can be set by screen.
6. Special protective device.
Technical Parameters:
|
Efficency（about） |
150pcs/min |
|
Non-Woven Supply |
60-100g/m² |
|
Pocket Spring Height |
80-250mm(can be customized) |
|
Wire Dia. |
Φ1.6-2.4mm(can be customized) |
|
Spring Core Dia. |
Φ55-75mm(can be customized) |
|
Non-Woven Width |
340-700mm |
|
Power Supply |
38KW |
|
Total Power |
50KW |
|
Air Requirement |
0.02m³/min 0.8MPa |
|
Gross Weight |
4500KG |
|
Size(Main machine) |
5500X1500X2000mm |
